Technical parameters:
Laser power 10W (R:2w/638nm+G:3w/532nm+B:5w/445nm)
12W (R:3w/638nm+G:3w/532nm+B:4w/445nm)
15W (R:4w/638nm+G:5w/532nm+B:6w/445nm)
20W (R:5w/638nm+G:5w/532nm+B:10w/445nm)
Scan angle + / - 30
Galvanometer 30/40/50kpps high speed optical fiber scanning mirror
Modulation mode analog
Working mode voice control, self-propelled, DMX512, master slave synchronization, ILDA software computer control
Cooling air cooling
Power consumption 150W
Ambient temperature -10-40 degrees
Input voltage 85-240v 50/60HZ
Animated laser adopts high-speed galvanometer scanning technology, patterns with broken pen, strobe, rotation, roll, move, stretch, zoom, gradual drawing, speed, color and other effects, with pattern size adjustment function, built-in beams and animated patterns, beam animation performance, laser advertising, laser projection
Size / net weight 55*44*41/23kgs
Carton size / gross weight 56*46*51.5cm/25KGS
Air box size / gross weight
56*46*51.5cm/43KGS
Suitable place for DISCO bar, night club, indoor and outdoor performance, fountain laser performance, etc.
